0452 series NANO2 Slo-Blo? Fuse

The NANO2? Slo-Blo? fuse has enhanced inrush withstand characteristics over the NANO2? Fast-Acting fuse.

  • Brand: Littelfuse
  • Classification: SMD Fuse
  • Voltage: 72V,125V
  • Current: 0.375A-12A
Description:

 The NANO2? Slo-Blo? fuse has enhanced inrush withstand characteristics over the NANO2? Fast-Acting fuse. The unique time delay feature of this fuse design helps solve the problem of nuisance "opening" by accommodating inrush currents that normally cause a fast-acting fuse to open.


Features:

? Small size

? Low temperature rerating

? Wide range of current rating available (0.375A to 12A)

? RoHS compliant and Halogen Free

? Wide operating temperature range



Applications:

? Notebook PC

? Storage system

? LCD/PDP TV

? Telecom system

? LCD monitor

? Wireless basestation

? LCD/PDP panel

? White goods

? LCD backlight inverter

? Game console

? Portable DVD player

? Office Automation equipment

? Power supply

? Battery charging circuit protection

? Networking

? Industrial equipment

? PC server

? Cooling fan system


Part Number
Ampere Rating
(A)
Amp Code
Max Voltage Rating
(V)
Interrupting Rating
Nominal Code Resistance
(Ohms)
Nominal Melting I2t(A2sec)
0452.375MRL

0.375

.375

125

50A @ 125 VAC/VDC
300 A @ 32 VDC
PSE:100 A @100 VAC

1.2000

0.101

0452.500MRL

0.500

.500

125

0.7000

0.240

0452.750MRL

0.750

.750

125

0.3600

0.904

0452001.MRL

001.

001.

125

0.2250
1.98
045201.5MRL

1.50

01.5

125

0.0930
3.65
0452002.MRL

2.00

002.

125

0.0625

8.20
045202.5MRL

2.50

02.5

125

0.0450
15.0
0452003.MRL

3.00

003.

125

0.0340
20.16
045203.5MRL

3.50

03.5

125

0.0224
26.53
0452004.MRL

4.00

004.

125

0.0186
34.40
0452005.MRL

5.00

005.

125

0.0136
53.72
0452007.MRL

7.00

007.

75

50 A @ 72 VAC
50 A @ 60 VDC
0.0105
123.83
0452008.MRL

8

008.

75

50 A@ 72 VAC
50 A@ 60 VDC
0.0088
137.34
0452012.MRL

12

012.

75

0.0061
260.46
