Part No.VRWM.max (V)VBR.min(V)CJ .typ(pF)Ppp @8/20μs(W)Ipp @8/20μs(A)IR.max(μA)Contact(kV)ChannelInnerDiagramPackagePDFJET363-5V-5566010080.2±305SOT-363JET363-5V-UL4560.37550.5±254SOT-363 VRWM：Rever
| Part No. | VRWM .max (V) | VBR .min (V) | CJ .typ (pF) | Ppp @8/20μs (W) | Ipp @8/20μs (A) | IR .max (μA) | Contact (kV) | Channel | Inner Diagram | Package | |
| JET363-5V-5 | 5 | 6 | 60 | 100 | 8 | 0.2 | ±30 | 5 |  | SOT-363 |  |
| JET363-5V-UL4 | 5 | 6 | 0.3 | 75 | 5 | 0.5 | ±25 | 4 | | SOT-363 | |
VRWM：Reverse Working Voltage
VBR：Snap-Back Voltage
CJ：Junction Capacitance
Ppp：Peak Pulse Power
Ipp：Peak Pulse Current
IR：Reverse Leakage Current
Contact：IEC 61000-4-2;Contact Discharge
