DetailspecificationNO.1DetailspecificationNO.2PartNo.RatedVoltageDCRatedCurrent(A)InterruptingRating*Resistance(Ohms)**Typ.TypicalMeltI2t***DC(A2S)JFC0402-0200FS32V200mA35A17500.0006JFC0402-
| Part Number | Rated Current (A) | Rated Voltage DC | Interrupting Rating | Resistance(mohms)**Typ | Typical Melt I2t**(A2sec) |
| JFC0402-0200FS | 0.20 | 32V | 35A@32V DC | 2250 | 0.0006 |
| JFC0402-0250FS | 0.25 | 1500 | 0.0010 | ||
| JFC0402-0315FS | 0.315 | 1000 | 0.0014 | ||
| JFC0402-0375FS | 0.375 | 780 | 0.0018 | ||
| JFC0402-0500FS | 0.50 | 500 | 0.0043 | ||
| JFC0402-0750FS | 0.75 | 220 | 0.011 | ||
| JFC0402-1100FS | 1.0 | 130 | 0.04 | ||
| JFC0402-1150FS | 1.5 | 78 | 0.06 | ||
| JFC0402-1200FS | 2.0 | 40 | 0.13 | ||
| JFC0402-1250FS | 2.5 | 24 | 0.20 | ||
| JFC0402-1300FS | 3.0 | 18 | 0.33 | ||
| JFC0402-1350FS | 3.5 | 14 | 0.45 | ||
| JFC0402-1400FS | 4.0 | 11 | 0.60 |
